Good Thermal Conductivity Thermal Grease Thermal Paste For Electronic Components IC, CPU, MOS

Good Thermal Conductivity Thermal Grease Thermal Paste For Electronic Components IC, CPU, MOS

Image Grand :  Good Thermal Conductivity Thermal Grease Thermal Paste For Electronic Components IC, CPU, MOS

Détails sur le produit:
Lieu d'origine: Chine
Nom de marque: Ziitek
Certification: RoHs
Numéro de modèle: TIG780-50HP
Conditions de paiement et expédition:
Quantité de commande min: 1kg
Prix: 0.1-10 USD/KG
Détails d'emballage: 1kg/can
Délai de livraison: 3-5 jours ouvrables
Capacité d'approvisionnement: 100 kg/journée
Description de produit détaillée
Nom des produits: Pâte thermique de graisse thermique à bonne conductivité thermique, pour composants électroniques IC couleur: gris
Construction & composition: Oxyde métallique/huile de silicone Densité: 2.3g/cm³
Conductivité thermique: 5,0 W/mK Impédance thermique ((%22C-in²/W) à 30 psi): 0,015
Mots-clés: Paste thermique Température de fonctionnement recommandée: -40 ~ 200 ℃

Good Thermal Conductivity Thermal Grease Thermal Paste For Electronic Components IC, CPU, MOS



TIG®780-56 Series is an environmentally friendly silicone based thermal paste designed to efficiently solve overheating problems in electronic devices and improve long-term reliability, TIG®780-50HP is a paste like material that can fully wet the surfaces of electronic components and heat sinks. It acts to fill the gaps between electronic components and heat sinks, eliminate air, and significantly improve heat dissipation eficiency (better than traditional thermal pads or ordinary silicone grease), thereby forming an extremely low thermal resistance interface and achieving excellent thermal conductivity efficiency.



Features



> High thermal conductivity
> Excellent low thermal resistance
> Good electrical insulation
> Excellent long-term stability
> Non toxic, environmentally friendly,and safe, meeting RoHS requirements


Applications lnclude


> Al server
> Industrial equipment
> Medical electronic devices
> LED TV,LED lighting fixtures
> Automotive Electronics (New Energy and Intelligence)
> High end consumer electronics and portable devices



Typical Properties of TIG®780-50HP Series
Property Value Test Method
Color Gray Visual
Construction &Compostion Metal oxide / Silicone oil Ziitek Test Method
Density 2.30 g/cm³ ASTM D792
Thermal Conductivity 5.0W/mK ASTM D5470
Bond line Thickness (mm) 0.008 ASTM D374
Thermal Impedance (℃·in²/W) @30 psi 0.015 ASTM D5470
Thermal Impedance (℃·in²/W) @50 psi 0.012 ASTM D5470
Recommended Operating Temp -40℃ to 200℃ *****
Viscosity(mPa.s) 200000 GB/T 10247



Packaging Specifications


Packaging specifications: 0.5kg,1kg,2kg;

If you have any other specification requirements, please contact our company.
